HLU Ultrasonic Liquid Level Meter
Ultrasonic liquid level meter combines ultrasonic sensors, temperature sensors, ultrasonic servo circuit, transmission circuit and uses SMD components and ASIC. All these features realize a concise and smart level transmitter.
Application :
●Non contact distance level measurement
●Food level monitoring
●Industrial fuel level measurement
●Mud water level measurement
Advantages
01Support M49*1.5 mm threaded into type installation and coil clamping type installation
02Less than 9°C Beam angle design ,less than 200ms responsible time to make sure more accuracy
03Housing adopts the NLEPE synthetic material IP66 waterproof
04High quality terminal blocks ,Excellent anti-jamming is strong, long term stability
Resources
Technical Data
|
Item |
Specification |
|
Range |
100m, 200m ,300m |
|
Blind |
≤500mm-800mm (according to range) |
|
Draft depth |
500mm |
|
Accuracy |
±0.5%F·S(default) |
|
Output signal |
4~20mA, RS485 |
|
Display mode |
Multi information and large screen LCD display |
|
Keyboard |
Five light touch buttons |
|
Operation temp. |
0~40°C(sensor),-10°C~50°C(instrument) |
|
Working power |
Built-in rechargeable lithium batteries,6h standby time,special charger |
|
Cable way |
Instrument :standard connector,sensor down-lead: standard 10m |
|
Application medium |
Flesh water, sea water |
|
Mounting model |
Instrument: hand-held portable;Sensor: Thread |
|
Defend grade |
Sensor:IP68 |
